КАМЕРА
Image Sensor: 1/2.8" SONY Starvis Back-illuminated CMOS sensor
Resolution: 5MP
Effective Pixels: 2616 (H)*1964 (V)
Compression: H.264/H.264+/H.265/H.265+/JPEG/AVI /MJPEG
Audio Compression: G711A/U,AAC
TV System: PAL/NTSC
Electronic Shutter: Time Auto: 1/3-1/100000Sec
Minimun Illumination Color: 0.003 lux@F1.6,AGC ON; B/W :0 lux with IR
S/N Ratio: 60dB
Scanning System: Progressive
Video Output: Network
Reset Button: Optional
ОБЪЕКТИВ
Focal Length & FOV: 2.7-13.5mm Motor Zoom, horizontal FOV 103°—29°, vertical FOV 54°—16°, diagonal FOV 124°—33°
Lens Type: Auto
Focus Control: Auto
Aperture: F1.6 - F3.3
Pixels: 5MP
РЕЖИМ НОЧНОГО ВИДЕНИЯ
Infrared LED: 42µ x 4PCS
Infrared Distance: 40M
IR Status: Auto Control
IR Power On: Smart, Manual & Timed mode
СЕТЕВЫЕ ХАРАКТЕРИСТИКИ
Ethernet RJ-45 (10/100Base-T)
Protocol: TCP/IP,IPv4/v6, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP ,PPPoE, NTP, SMTP, UDP, SNMP,Qos,802.1x
ONVIF: Support ONVIF 19.12(Profile S/T/G)
P2P: YES
POE Internal, Support IEEE 802.3af
Main Stream 1 2592*1944@30fps
Main Stream 2 2560*1440@30fps
Main Stream 3 1920*1080@30fps, 1280*720@30fps
Sub Stream 1 1280*720@30fps
Sub Stream 2 720*480@30fps
Sub Stream 3 352*288@30fps
Tri Stream 1280*720@30fps, 720*480@30fps, 352*288@30fps
IE Browser: IE8-11, Google Chrome, Firefox , Mac Safari
Smart Phone: iPhone, Android
ИИ ФУНКЦИИ
Intelligent Analysis Face Detection, Intrusion Detetion(based on human and Vehicle Detection), Line Cross Detetion(based on human and Vehicle Detection), Loiter Detetion, People Gather Detecion(based on human detection), Motion detection based on human detection
ФУНКЦИИ
Day/Night Color/ B&W (IR-CUT )
Image Config Saturation/Brightness/Contrast /Sharpness, Mirror, 3D NR , White Balance, Anti Flicker, Video Tampering, HLC, Distortion
Corridor Pattern: Support
Defog: Mode Support
ROI: Support
BLC: Support
WDR: 120dB
Motion Detection: Support (support enable the detection based on human movement only)
Privacy Masking: 3 Rectangular Zone
Recording Mode: NVR/CMS/Web
Language: Chinese Simplified, Chinese Traditional, English, Bulgarian, Polish, Arabic, German, Русский, French, Korean, Portuguese, Japanese, Turkish, Spanish, Hebrew, Italian, Nederlands, Czech, Vietnamese
ИНТЕРФЕЙСЫ
Audio Optional Audio IN/OUT
Alarm Optional 1 Channel Input/Ouput
SD Card Slot Optional Internal, Support Max 1TB,Built in 4G Storage
ОСНОВНЫЕ ХАРАКТЕРИСТИКИ
Housing: Metal ,IP67
Anti-cut Bracket: NO
IR Cut Filter: YES
Operation Temperature: -30℃ ~ +60℃ RH95% Max
Storage Temperature: -20℃ ~ +60℃ RH95% Max
Power Source: DC12V±10%, 950mA
Dimension: ￠140 x 128(H)mm
Weight: 1200g
